Protection Plug Form Z2
Protection Plug Form Z2
Built with a high-strength alloy steel body and carbide tip, this dead center provides stable support and wear-resistant performance for precision turning and grinding applications.
Product Details & Technical Resources
CAD Drawings
Access product dimension drawings and structural references to support selection, installation and project planning.
| 订单号 order No. |
d1 | d2 | h1 | L1 | L2 |
| Z2-16S | 16 | 40 | 18 | 45 | 13 |
| Z2-20S | 20 | 50 | 23 | 56 | 16 |
| Z2-30S | 2 | 68 | 28 | 71 | 16 |
| Z2-40S | 40 | 83 | 32.5 | 83 | 20 |
| Z2-50S | 50 | 98 | 35 | 98 | 20 |
| Z2-60S | 60 | 123 | 42.5 | 114 | 20 |
Technical Specifications
Access product dimension drawings and structural references to support selection, installation and project planning.
| 订单号 order No. |
d1 | L1 | d2 |
| A2-16×60 | 16 | 60 | 40 |
| A2-20×70 | 20 | 70 | 50 |
| A2-25×80 | 25 | 80 | 58 |
| A2-25×200 | 25 | 200 | 58 |
| A2-30×100 | 30 | 100 | 68 |
| A2-30×240 | 30 | 240 | 68 |
| A2-40×120 | 40 | 120 | 83 |
| A2-40×200 | 40 | 200 | 83 |
| A2-40×320 | 40 | 320 | 83 |
| A2-50×135 | 50 | 135 | 98 |
| A2-50×220 | 50 | 220 | 98 |
| A2-50×400 | 50 | 400 | 98 |
| A2-60×150 | 60 | 150 | 123 |
| A2-60×480 | 60 | 480 | 123 |
